Plastic Injection Molding Machine Hxm218 Produce Egg Tray/ Full Automatic Injection Molding Machine
Package size per unit product 564.00cm * 134.00cm * 210.00cm Gross weight per unit product 6600.000kg 1.Picture plastic
Basic Info
Model NO. | HXM218 |
Structure | Horizontal |
Plastic Type | PS,ABS,PP,PE,HDPE,PA,EVA |
Plasticizing Way | Screw Type |
Clamping Way | Hydraulic & Mechanical |
Automation | Automatic |
Computerized | Computerized |
Certification | CE, ISO9001:2008 |
Energy Saving | Servo Energy Saving |
After Sales Service | Engineers Avaiable to Service Machine |
Voltage | 380V/50Hz, According to Countries |
Showroom Locate | Malaysia,Russia,Turkey,Uzbekistan |
Condition | New |
Injection Weight | 400g PS |
Space Between Tie Bar | 520X520 |
Machine Weight | 6.6 Ton |
Transport Package | Standard Package |
Specification | 5.745x1.34x2.125 |
Trademark | Highsun |
Origin | China |
HS Code | 8477101090 |
Production Capacity | 7000 Sets / Year |
Packaging & Delivery
Package size per unit product 564.00cm * 134.00cm * 210.00cm Gross weight per unit product 6600.000kgProduct Description
1.PictureMODEL:HXM218 | |||||
TECHNICAL PARAMETER TABLE | A | B | C | ||
INJECTION UNIT | SCREW DIAMETER | mm | 45 | 50 | 55 |
SCREW L/D RATIO | L/D | 22.2 | 20 | 18.2 | |
INJECTION CAPACITY IN THEORY | cm3 | 349 | 431 | 522 | |
INJECTION WEIGHT(PS) | g | 324 | 400 | 485 | |
oz | 11.4 | 14.1 | 17.1 | ||
INJECTION PRESSURE | MPa | 210 | 170 | 140 | |
INJECTION RATE | g/s | 128 | 158 | 192 | |
PLASTICIZING CAPACITY | g/s | 18 | 25 | 32 | |
SCREW SPEED | rpm | 200 | |||
CLAMPING UNIT | CLAMPING FORCE | KN | 2180 | ||
MOVING MOULD-PLATE STROKE | mm | 520 | |||
MAX. MOULD HEIGHT | mm | 580 | |||
MIN. MOULD HEIGHT | mm | 200 | |||
SPACE BETWEEN TIE-BARS (W×H) | mm | 520x520 | |||
HYDRAULIC EJECTOR FORCE | mm | 80 | |||
HYDRAULIC EJECTOR STROKE | KN | 150 | |||
EJECTOR NUMBER | n | 9 | |||
OTHERS | PUMP PRESSURE | MPa | 16 | ||
MOTOR /DRIVING POWER | KW | 18.5/23 | |||
HEATING CAPACITY | KW | 13.55 | |||
MACHINE DIMENSION (L×W×H) | m | 5.745x1.34x2.125 | |||
MACHINE WEIGHT | t | 6.6 | |||
OIL TANK CAPACITY | L | 281 |
